BRAND NEW
ICEX1600.1 BANDA One Channel 1600 Watts Max
@ 1 Ohm Car Audio Mono Amplifier
Total Power 14,4 @ 1 Ohm - 2300 WRMS
Total Power 14,4 @ 2 Ohms -1700 WRMS
Total Power 12,6 @ 1 Ohm -1600 WRMS
Total Power 12,6 @ 2 Ohms -1300 WRMS
Efficiency @ 2 Ohms -81%
Efficiency @ 1 Ohm -70%
Input Voltage - 9 – 15V
Input Impedance -100K Ohms
THD+Noise - 0.1%
Input Sensitivity -155mV – 8V
SNR - 84dB
Frequency Response (Key OFF) - 5 to 22kHz (-3dBs)
Frequency Response - 20 to 20kHz (-3dBs)
Bass Bosst @ 45Hz
Variable 0 to +18dBs
HPF (Subsonic) - 20 to 80Hz @ 12dB/octave Linkwitz-Riley
LPF (Crossover) - 80 to 20kHz @ 12dB/octave Linkwitz-Riley
Recommended Fuse - 80 A
Current at Rest - 2 A
Average Current Draw (Sinusoidal) -180 A
Average Current Draw (Music) - 90 A
Power Wire Gauge (min. Recommended)
16mm / 5 AWG
Speaker Wire Gauge (min. Recommended)
2 x 4mm / 2 x 11 AWG
Weight (Lb) -7.2
Height (in) -2.2
Width (in) -8.4
Depth (in) -9.7
