Kenwood

Kenwood KFC-1366S Pair 5.25" Car Audio Speakers 260W Peak Power

Kenwood KFC-1366S Pair 5.25" Car Audio Speakers 260W Peak Power

$49.00
$49.00
Sale Sold out

KENWOOD AUTHORIZED RETAILER

KFC-1366S  5-1/4" Coaxial Speakers - Pair

  • Frequency Response 45Hz - 22kHz
  • Mounting Depth 1-3/4”

Sound Field Enhancer

To improve sound quality

Enlarged magnet circuit

To realize clear sound

Only 5/16"of mounting height

To fit for wider car selection

FEATURES LIST

Peak Input Power

  • 260W

Rated Input Power

  • 30W Impedance 4 ohms

Woofer Features

  • 5-1/4inch PP Cone

Tweeter Features

  • 1inch Balanced Dome Tweeter

Specifications

  • Sensitivity: 89dB / W / m
  • Frequency Response: 45Hz - 22kHz
  • Cutout Diameter: 4-7/16inch
  • Mounting Depth: 1-3/4inch
  • Gross Weight: 2.2lbs
  • Weight of Magnet (Woofer): 0.35lbs



SPECS



KFC-1366S
Woofer Size 130mm 5.25in
Diaphragm PP Cone
Surround Cloth
Basket Steel : Black
Magnet Ferrite φ70*t10
Tweeter Size 25mm 1in
Diaphragm PEI Balanced Dome
Woofer (Unit) Width (w_Gr) 157.0mm 6-3/16in
Width (w/o_Gr) 130.0mm 5-1/4in
Height (w_Gr) 157.0mm 6-3/16in
Height (w/o_Gr) 130.0mm 5-1/4in
Cutout Diameter 112.0mm 4-7/16in
Depth (w_Gr) 66.5mm 2-5/8in
Depth (w/o_Gr) 50.8mm 2in
Mounting Depth 43.5mm 1-3/4in
WEIGHT with Grille (pc.) 475g 1.0lbs
without Grille (pc.) 423g 0.9lbs
Gross Weight 1013g 2.2lbs
Weight of Magnet 160g 5.6oz
POWER HANDLING Peak Power 260W
Rated Power 30W
SENSITIVITY 89db / W at 1m
FREQUENCY RESPONSE 45Hz- 22Hz
Impedance 4ohms
CROSSOVER FREQUENCY -
ACCESSORY Grille *2
Screw sets
Tapping Screw φ4x25*8
Speed Nut *8
Speaker Cord 0.3m*2

Carton Box 4 Color
L 312.0mm
W 180.0mm
D 86.0mm
