Amplifier Class - D
Total Power 14,4 @ 2 Ohms - 3700 WRMS
Total Power 14,4 @ 4 Ohms - 2300 WRMS
Total Power 12,6 @ 2 Ohms - 3000 WRMS
Total Power 12,6 @ 4 Ohms - 1700 WRMS
Efficiency @ 4 Ohms - 84%
Efficiency @ 2 Ohms - 80%
Input Voltage - 9 – 15V
Input Impedance -100K Ohms
THD+Noise - <1%
Input Sensitivity - 140mV – 8V
SNR -86dB
Frequency Response (Key OFF) -5 to 500Hz (-3dBs)
Frequency Response - 20 to 500Hz (-3dBs)
Bass Bosst @ 45Hz
Variable 0 to +18dBs -
HPF (Subsonic)
20 to 80Hz @ 12dB/octave Linkwitz-Riley
LPF (Crossover)
80 to 500Hz @ 12dB/octave Linkwitz-Riley
Recommended Fuse -150 A
Current at Rest - 2 A
Average Current Draw (Sinusoidal) - 315 A
Average Current Draw (Music) -155 A
Power Wire Gauge (min. Recommended) -21mm / 4 AWG
Speaker Wire Gauge (min. Recommended) - 2 x 4mm / 2 x 11 AWG
Weight (Lb) -10.8
Height (in) - 2.4
Width (in) -10.6
Depth (in) - 12.3
BRAND NEW
FREE ROUND SHIPPING
