AUTOTEK ATS65CXS
ATS Series speakers from Autotek are available in the most popular sizes to fit into factory speaker locations with very little or no modification.
They are perfect for a first car or a full restoration. They are designed to easily disappear into the stock speaker locations and behind factory
grilles but the ATS speakers deliver huge sound. Autotek full-range speakers are packed with technology to deliver great music,
no matter what is loaded into your CD player or mobile device. Look closely for durable moisture-resistant foam speaker surrounds,
bass-enhancing polypropylene cones and super-output Neo-Mylar soft-dome tweeters. This pair of shallow-mount 6.5-inch, coaxial,
300-watt ATS Series Speakers includes installation hardware and they have a
chassis depth from the flange of 1.65 inches. Get great sound at a great price!
Specifications
·
RMS POWER HANDLING(CEA426B)
150 watts
·
PEAK POWER HANDLING (CEA426B)
300 watts
·
SPEAKER IMPEDANCE
4 Ω
· FREQUENCY RESPONSE +/- 10DB
·
FREQUENCY RESPONSE +/- 3DB
60Hz-20kHz
·
SENSITIVITY (1 WATT/1 METER)
88dB
·
CROSSOVER POINT
4K Hz
·
CROSSOVER SLOPE
12dB
·
MOUNTING DIAMETER/CUT OUT
5.59
·
OUTSIDE DIAMETER
7.01
·
MOUNTING DEPTH/CHASSIS DEPTH
1.65
·
PRODUCT DIMENSIONS
14.88 x 8.5 x 4.13 in
37.7 x 21.5 x 10.4 cm
·
PRODUCT WEIGHT
3.4 lbs (1.5kg)
Features & Benefits
·
TWEETER DOME MATERIAL: Neo-Mylar Soft Dome
Tweeter
Impact Resistant Tweeter Elements
·
SURROUND: UV Resistant Rubber
Surround
Moisture Resistant Rubber Surround with high Mid-Bass Impact
·
CONE: Silver
Alpha-Cellulose Polypropylene Cones - Treated Pressed Paper Cone
Produces musical midrange and bass tones while remaining light weight
·
SURROUND / CONE COUPLING: High Temperature
Adhesive
The cone/surround connection utilizes a high temp adhesive which assure the
cone and surround do not separate in high power uses or extremes of weather
·
GASKET: Textured ABS
Assures a ridged linear seal to the mounting surface
·
TINSEL LEADS: Braided
Highly conductive while remain flexible during high power applications
·
VOICE COIL: Pure Copper
Creates strong magnetic field with a very thin extrusion
·
VOICE COIL FORMER: Kapton
Lightweight and efficiently dissipates heat
·
SPIDER: Epoxy infused
Natural Fiber
Natural fiber allows flexibility while the epoxy which gives strength during
the manufacturing process.
·
COOLING SYSTEM: Over-Coil
Air is exchanged over the voice coil through the spider
·
CROSSOVER TYPE: Passive
Butterworth
Smooth transition of frequencies from midrange/midbass to the tweeter element
·
CROSSOVER SPECIAL: 6dB Internal
Integrated into the design to assure smooth midrange to tweeter frequency
transitions
·
FRAME: Anti-Resonant
Stamped Steel Frame
Very strong with minimal harmonics or distortions from flex or ringing
·
MOTOR: Ferrite
Magnet
Creates a strong magnetic field while remaining small enough to fit nearly
every application
·
CONNECTORS: Spade
Use spade connectors or solder direct for the best connection
·
GRILLS: Yes
Protects the speaker from accidental damage. Not used if speaker is mounted
behind vehicle panel
·
TWEETER MATERIAL: Neo-Mylar Soft
Dome
Great sound quality and increased reliability
·
TWEETER SIZE: 1 inch
Clear highs while handling plenty of power without sounding harsh
·
TWEETER SURROUND MATERIAL: Kapton
Lightweight and efficiently dissipates heat
Customers will receive 2 orders per purchase (4 speakers)
