Kenwood DMX8709S 6.8” Digital Car Receiver Wireless Apple CarPlay Android Auto

Kenwood DMX8709S

Digital Media Receiver with Bluetooth Wired and WIRELESS APPLE CARPLAY

Wired and WIRELSSS Android Auto

6.8" Touch Screen, USB Mirroring for Android, 3 Preouts 4.0V

6.8" WVGA Monitor with Capacitive Touch Panel

Android Auto™ & Android Auto™ Wireless

Wired and Wireless Apple CarPlay™

USB Mirroring for Android

13 Band EQ & Digital Time Alignment

3 Camera Inputs

Short Chassis

3 Preouts 4.0V



Works with Apple CarPlay

Works with Android Auto

WiFi Certified

iDatalink Maestro Ready

Made for iPhone

Bluetooth Built-In

SiriusXM Ready



Capacitive Touch Panel

Clear glass display with swipe functionality that provides superior picture and touch panel control.



Android USB Mirroring

Solution for seamlessly displaying and controlling your smartphone apps on a screen via a USB connection on select Android devices.



3 Camera Inputs

Optional camera connection method for up to 3 cameras in various configurations.



Parking Guidelines

Parking guidelines (requires installation of compatible backup camera) that enhance the effectiveness of a backup camera.



Music Mix

Up to 5 Bluetooth® devices can be paired to the receiver at the same time. You can enjoy audio streaming just by switching the devices with your friends or family.



Dual Phone Connection

While you are connected through Bluetooth, with a touch of a button you can switch between two phones.



Graphic EQ / Digital Time Alignment

13-Band equalizer and DTA gives optimal tuning enhancements for listeners.



Drive EQ

Boosts specific frequencies in the audio signal to overcome the negative impact of road noise.



Variable Color Illumination

Bright variable color LEDs can be adjusted to match any

color dash lighting.



Short Chassis

With receivers shorter in depth than any of our previous models, installation is made easier in a wider range of cars than ever before.

Smartphone Connectivity

Safe, Smart and Comprehensive Control with Apple CarPlay

Apple CarPlay is a safer way to use your iPhone in the car. Simply talk to Siri or touch the receiver’s display to get directions from Apple Maps, make phone calls, listen to voicemail, send and receive texts, and listen to music from Apple Music or your favorite 3rd party streaming services like Pandora and Spotify, all in a way that allows you to stay focused on the road. With the latest iOS version (iOS 12.0 and higher), 3rd party navigation apps like Google Maps™ and Waze™ are also supported.

KENWOOD Wi-Fi receivers now support Apple CarPlay wirelessly (compatible phone required).



Android Auto for Easy Connectivity

Android Auto was designed with safety in mind, helping you to minimize distractions and stay focused on the road. KENWOOD’s multimedia receivers combine an intuitive voice controlled interface with a large touch screen and superior sound quality, making it the perfect complement for your in-car life. You can even listen to and control music from your favorite streaming services like Pandora and Spotify. Navigate to where you need to with Google Maps or Waze. KENWOOD Wi-Fi receivers also support Android Auto wirelessly (compatible phone required).



- To use Android Auto on your car display, you’ll need an Android Auto compatible vehicle or aftermarket stereo, an Android phone running Android 6.0 or higher, and the Android Auto app.



True Mirroring via USB,

2-Way Touch Control for Android

Allows you to display and control your Android smartphone on the screen of the receiver.

You can enjoy your favorite apps on a large display and with impressive sound quality. Before starting, just install the free app “Mirroring OA for KENWOOD” on your smartphone and connect it to KENWOOD receiver via a USB cable and Bluetooth.



Mirroring for KENWOOD App

For more information, visit here.



HDMI Input

Display your smartphone screen or other device via an HDMI cable (and third party adapter as applicable) on the monitor. KCA-HD200 optional HDMI cable sold separately.



Streaming Music

Listen to popular music applications and music stored on your device with basic audio controls.



Equipped with the Intuitive KENWOOD Music Mix

Up to 5 Bluetooth® devices can be connected to the receiver at the same time, allowing you to take turns streaming music with your friends and family.



Dual Phone Connection

While you are connected through Bluetooth, with a touch of a button you can switch between two phones.



Optimal Sound Performance with 13 Band Graphic EQ and Time Alignment

Use the graphic equalizer to tailor the sound quality to your unique tastes. Additional sound staging is available with the Time Alignment feature, designed to provide optimal sound performance.



Playable Video & Audio Files

You can play back from USB devices audio and video files compressed in various formats.



ENHANCED VEHICLE INTEGRATION

Compatible with both the Automotive Data Solutions iDatalink Maestro RR and RR2 (sold separately)* for enhanced system vehicle integration. In addition to providing the seamless factory integration experience you have become accustomed to with the RR, these models feature expanded support when connected to the RR2, including an Advanced Driver Assistance Systems (ADAS) Widget, Customizable Accessory Controls, and compatibility with specific ESCORT radar detector systems (sold separately).



*Available features vary by vehicle





Rear View Camera Input with Parking Guidelines

An optional rear view camera enhances safety while backing up and monitoring behind your vehicle. Built-in, adjustable parking guidelines further add to its effectiveness.





3 Camera Inputs

To enable a smarter driving experience, receivers featuring 3 camera inputs allow for the utmost in convenience, flexibility, and safety. With 3 camera inputs, you can connect a front camera, a rear camera and a third camera which can be used for trailers or caravans. Alternatively, 3 camera inputs support several other configurations, including the connection of 2 blind spot cameras and a reverse camera. Camera switching is available using on screen controls and manual switchers.



Additional Features

Convenient and Easy-to-Use Capacitive Touch Panel

Provides a high contrast ratio, crystal clear display and vivid text. Easy to use widgets provide access to information screens with a swipe.



SiriusXM Radio Ready

Access additional music, sports and entertainment content on the go with SiriusXM Radio.

(Optional SiriusXM tuner required, sold separately)



Short Chassis Design

Only 2-15/16" (75mm) of depth for more flexible installation.



Remote Control (Optional)

This receiver unit can be operated using the optional remote control KCA-RCDV340.





Monitor Section	Picture size	6.75 inches(diagonal) wide
	W x H	151.8 mm x 79.7 mm, 6 x 3-1/7 inch
	Display system	TN LCD panel
	Drive system	TFT active matrix system
	Number of pixels	1,152,000
		800H x 480V x RGB
	Effective pixels	99.99%
	Pixel arrangement	RGB striped arrangement
	Back lighting	LED
USB I/F Section	Connector Type	Type-A
	USB Standard	USB2.0 Full Speed / High Speed
	File System	FAT 16/32, exFAT
	Maximum Power Supply Current	DC5V=1.5A
	D/A Converter	24Bit
	Audio Decoder	MP3 / WMA / AAC / WAV / FLAC
	Video Decoder	MPEG1/2,MPEG4 / WMV / H.264 / MKV
	Frequency response 192k Sampling	20 to 20,000 Hz
	96k Sampling	20 to 20,000 Hz
	48k Sampling	20 to 20,000 Hz
	44.1k Sampling	20 to 20,000 Hz
	Total harmonic distortion 1kHz	0.010%
	Signal to Noise ratio	98.5dB
	Dynamic range	89dB
Wi-Fi	IEEE Standard	802.11 a/b/g/n/ac
	Frequency Range	Dual Band ( 2.4GHz / 5GHz )
	Channels	Auto(1-11ch)
		Auto(149,153,155,157,161ch)
	Transfer rates (MAX)	11a:54 Mbps / 11b: 11 Mbps
		11g: 54 Mbps / 11n:150 Mbps / 11ac:433 Mbps
Bluetooth Section	Technology	Bluetooth Ver5.0
	Frequency	2.402 to 2.480 GHz
	Maximum Communication range	Line of sight approx.10m(32.8ft)
	Audio Codec	SBC / AAC
	Multi Profile Support	Multi Profile
	Profile	HFP (V1.8) (Hands Free Profile)
		SPP (Serial Port Profile)
		A2DP (V1.3.2) (Advanced Audio Distribution Profile)
		AVRCP (V1.6.2) (Audio/Video Remote Control Profile)
		PBAP (Phonebook Access Profile)
HDMI I/F Section	Connector Type	Type-D
	Input Resolution	VGA (640x480p @59.94Hz/60Hz)
		480p (720x480p @59.94Hz/60Hz)
	Input Audio Type	32K/44.1K/48K/88.2K/96K/176.2K/192K 16/20/24-bit Linear PCM
DSP Section	Equalizer	13Band
	Band Frequency	62.5/100/160/250/400/630/1k/1.6k/2.5k/4k/6.3k/10k/16k[Hz]
	Gain	-9/-8/-7/-6/-5/-4/-3/-2/-1/ 0/ 1/ 2/ 3/ 4/ 5/ 6/ 7/ 8/ 9 [dB]
	Tweeter Gain	-8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 [dB]
	HPF Frequency	Through/30/40/50/60/70/80/90/100/120/150/180/220/250[Hz]
	Slope	-6/-12/-18/-24[dB/Oct.]
	Gain	-8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
	LPF Frequency	30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250 Hz/ Through
	Slope	-6/ -12/ -18/ -24 dB/Oct.
	Gain	-8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
	Phase	Normal/ Reverse
	Tweeter HPF Frequency	1k/1.6k/2.5k/4k/5k/6.3k/8k/10k/12.5k [Hz]
	Slope	-6/ -12 [dB/Oct.]
	Gain	-8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 [dB]
	Phase	Normal/ Reverse
	Mid Range HPF Frequency	Through/30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250[Hz]
	Slope	-6/ -12 [dB/Oct.]
	Mid Range LPF Frequency	1k/1.6k/2.5k/4k/5k/6.3k/8k/10k/12.5k/Through [Hz]
	Slope	-6/ -12 [dB/Oct.]
	Gain	-8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 [dB]
	Phase	Normal/ Reverse
	Subwoofer LPF Frequency	30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250/ Through [Hz]
	Slope	-6/ -12 [dB/Oct.]
	Gain	-8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 [dB]
	Phase	Normal/ Reverse
FM	Frequency range (Frequency step)	87.9MHz to 107.9MHz
		(200kHz)
	Usable sensitivity	7.2 dBf
	S/N:30dB	0.63 μV / 75 Ohms
	Quieting sensitivity	15.2 dBf
	DIN S/N:46dB	1.58 μV / 75 Ohms
	Frequency response	30Hz to 15kHz
	(±3.0dB)
	S/N(dB)	68 dB(MONO)
	Selectivity	Over 80dB (±400kHz)
	Stereo separation	40 dB(1 kHz)
AM	Frequency range (Frequency step)	530kHz to 1700kHz
		(10kHz)
	Usable sensitivity	29 dBμ (28.2μV)
Video	Color system of external video input	NTSC/PAL
	External video input level (RCA jacks)	1 Vp-p / 75 Ohms
	External video input level (Mini jacks)	1 Vp-p / 75 Ohms
	External audio max input level (RCA jacks)	-
	External audio max input level (Mini jacks)	2 V / 25 kOhms
	Video Input level (RCA jacks)	1 Vp-p / 75 Ohms
	Video Output level (RCA jacks)	1 Vp-p / 75 Ohms
Audio	Maximum Power Output (Front&Rear)	50Wx4
	Typical Power Output (Front&Rear)	Full Bandwidth Power
		(at less than 1%THD)
		22Wx4
	Output frequency band	20 to 88,000Hz
	Preout level (V)	4V / 10kOhms
	Preout impedance (Ω)	=< 600 Ohms
	Speaker Impedance (Ω)	4 to 8 Ohms
General	Operating voltage	12V DC Car Battery
	Installation Dimensions WxHxD
	(Main Unit Installation size)	180mm x 100mm x 75mm
		7-1/16. x 3-15/16 x 2-15/16 inch
	(with Sleeve)	182mm x 111mm x 74mm
		7-3/16 x 4-3/8 x 2-15/16 inch
	Weight Main unit	1.2 kg
		2.7 lb
		(Trim plate and Mounting sleeve: Included)
