Total Power 14,4 @ 2 Ohms -1650 WRMS
Total Power 14,4 @ 4 Ohms -1050 WRMS
Total Power 12,6 @ 2 Ohms -1200 WRMS
Total Power 12,6 @ 4 Ohms - 800 WRMS
Efficiency @ 4 Ohms - 86%
Efficiency @ 2 Ohms - 78%
Input Voltage - 9 – 15V
Input Impedance -100K Ohms
THD+Noise - 0.1%
Input Sensitivity -190mV – 4V
SNR - 88dB
Frequency Response (Key OFF) - 5 to 22kHz (-3dBs)
Frequency Response - 20 to 20kHz (-3dBs)
Bass Boost @ 45Hz
Variable 0 to +18dBs
HPF (Subsonic) - 20 to 80Hz @ 12dB/octave Linkwitz-Riley
LPF (Crossover) - 80 to 20kHz @ 12dB/octave Linkwitz-Riley
Recommended Fuse - 60 A
Current at Rest -1.5 A
Average Current Draw (Sinusoidal) -150 A
Average Current Draw (Music) -75 A
Power Wire Gauge (min. Recommended) -16mm / 4 AWG
Speaker Wire Gauge (min. Recommended) - 2 x 2,5mm / 2 x 11 AWG
Weight (Lb) - 6.9
Height (in) - 2.2
Width (in) -8.4
Depth (in) -9.7
