Total Power 14,4 @ 1 Ohm -1100 WRMS
Total Power 14,4 @ 2 Ohms - 700 WRMS
Total Power 12,6 @ 1 Ohm - 800 WRMS
Total Power 12,6 @ 2 Ohms - 550 WRMS
Efficiency @ 2 Ohms - 82%
Efficiency @ 1 Ohm - 70%
Input Voltage - 9 – 15V
Input Impedance - 100K Ohms
THD+Noise- 0.1%
Input Sensitivity - 125mV – 4V
SNR - 86dB
Frequency Response (Key OFF)- 5 to 22kHz (-3dBs)
Frequency Response - 20 to 20kHz (-3dBs)
Bass Boost @ 45Hz
Variable 0 to +18dBs
HPF (Subsonic) - 20 to 80Hz @ 12dB/octave Linkwitz-Riley
LPF (Crossover) - 80 to 20kHz @ 12dB/octave Linkwitz-Riley
Recommended Fuse - 50 A
Current at Rest -1.0 A
Average Current Draw (Sinusoidal) -94 A
Average Current Draw (Music) - 45 A
Power Wire Gauge (min. Recommended) - 10mm / 7 AWG
Speaker Wire Gauge (min. Recommended) - 2 x 2,5mm / 2 x 13 AWG
Weight (Lb) - 6.8
Height (in) - 2.2
Width (in) - 8.4
Depth (in) - 9.7
