Kenwood
Kenwood DMX129BT 6.8" Digital Multimedia Receiver USB Mirror Android Bluetooth
Kenwood DMX129BT 6.8" Digital Multimedia Receiver USB Mirror Android Bluetooth
Regular price
$179.00
Regular price
Sale price
$179.00
Unit price
/
per
Couldn't load pickup availability
AUTHORIZED KENWOOD DEALER
BRAND NEW
KENWOOD DMX129BT
DMX129BT 6.8" Monitor Digital Multimedia Receiver (NO CD / NO DVD)
6.8" WVGA Monitor
USB Mirroring Ready for Android
13 Band EQ with Digital Time Alignment
Rear View Camera Input with Parking Guidelines
Built-in Bluetooth®
2 Preouts 2V with Subwoofer out
Made for iPhone
Capacitive Touch Panel
Clear glass display with swipe functionality that provides superior picture and touch panel control.
Android USB Mirroring
Solution for seamlessly displaying and controlling your smartphone apps on a screen via a USB connection on select Android devices.
Parking Guidelines
Parking guidelines (requires installation of compatible backup camera) that enhance the effectiveness of a backup camera.
Graphic EQ / Digital Time Alignment
13-Band equalizer and DTA gives optimal tuning enhancements for listeners.
Short Chassis
With audio receivers shorter in depth, installation is made easier in a wider range of cars.
Smartphone Connectivity
True Mirroring via USB,
2-Way Touch Control for Android
Allows you to display and control your Android smartphone on the screen of the receiver. You can enjoy your favorite apps on a large display and with impressive sound quality.
The Best Audio Experience
Optimal Sound Performance with 13 Band Graphic EQ and Time Alignment
Use the graphic equalizer to tailor the sound quality to your unique tastes. Additional sound staging is available with the Time Alignment feature, designed to provide optimal sound performance.
Playable Video & Audio Files
You can play back from USB devices audio and video files compressed in various formats.
Video Codec Playable up to
MPEG4 1920 × 1080p
H.264 1920 × 1080p
MKV 1920 × 1080p
Music Codec Playable up to
FLAC ～192kHz / ～24bit
WAV ～192kHz / ～24bit
Rear View Camera Input with Parking Guidelines
An optional rear view camera enhances safety while backing up and monitoring behind your vehicle. Built-in, adjustable parking guidelines further add to its effectiveness.
Convenient and Easy-to-Use Capacitive Touch Panel
Provides a high contrast ratio, crystal clear display and vivid text.
Short Chassis Design
Only 2-15/16" (75mm) of depth for more flexible installation.
| Main Unit | Monitor Section | Picture size | 6.75 inches (diagonal) wide |
|---|---|---|---|
| W x H | 151.8 mm x 79.7 mm, 5-15/16. x 3-1/8 inch | ||
| Display system | TN LCD panel | ||
| Drive system | TFT active matrix system | ||
| Number of pixels | 1,152,000 | ||
| 800H x 480V x RGB | |||
| Effective pixels | 99.99% | ||
| Pixel arrangement | RGB striped arrangement | ||
| Back lighting | LED | ||
| USB I/F Section | USB Standard | USB2.0 High Speed | |
| Connector | Type-A | ||
| File System | FAT 16 / 32 / exFAT / NTFS | ||
| Maximum Power Supply Current | DC5V(DC logo) 1.5A | ||
| D/A Converter | 24 Bit | ||
| Audio Decoder | MP3/ WMA/ WAV/ AAC/ FLAC | ||
| Video Decoder | MPEG1/ MPEG2/ MPEG4/ H.264/ MKV | ||
| Frequency response 192k Sampling | 20 - 20,000 Hz | ||
| 96k Sampling | 20 - 20,000 Hz | ||
| 48k Sampling | 20 - 20,000 Hz | ||
| 44.1k Sampling | 20 - 20,000 Hz | ||
| Bluetooth Section | Bluetooth Specification Version | Bluetooth V5.0 | |
| Frequency | 2.402 – 2.480 GHz | ||
| RF Output Power (E.I.R.P.) | +8 dBm (AVE), Power Class 1 | ||
| Maximum Communication range | Line of sight approx.10m (32.8ft) | ||
| Audio Codec | SBC / AAC | ||
| Multi Profile Support | Multi Profile | ||
| Profile | HFP(Hands Free Profile) 1.6 | ||
| SPP(Serial Port Profile) | |||
| A2DP(Advanced Audio Distribution Profile) 1.2 | |||
| AVRCP(Audio/Video Remote Control Profile) 1.5 | |||
| PBAP(Phonebook Access Profile) 1.2 | |||
| FM | Frequency range (Frequency step) | 87.9 - 107.9 MHz (200kHz) | |
| Usable sensitivity | 16.2dBf | ||
| S/N:30dB | 1.8μV/75Ω | ||
| Frequency response(±3.0dB) | 30Hz - 14kHz | ||
| S/N Ratio(dB) | 50dB (MONO) | ||
| Stereo separation | 35 dB (1 kHz) | ||
| AM | Frequency range (Frequency step) | 530 - 1700 kHz (10kHz) | |
| Usable sensitivity | 99μV (40 dBμ) | ||
| Video | Color system of external video input | NTSC/ PAL | |
| External video input level (RCA) | 1 Vp-p / 75 Ω | ||
| External video input level (RCA, AV-In) | 1 Vp-p / 75 Ω | ||
| External audio max input level (RCA, AV-In) | 1.5 V / 25 kΩ | ||
| Video Output level (RCA) | 1 Vp-p / 75 Ω | ||
| Audio | Maximum Power (Front&Rear) | 45Wx4 | |
| Full Bandwidth Power (Front&Rear) | 16Wx4 | ||
| Output frequency band | 20 - 20,000 Hz | ||
| Preout level (V) | 2 V / 10 kΩ | ||
| Preout impedance (Ω) | 1.4 kΩ | ||
| Speaker Impedance (Ω) | 4 - 8 Ω | ||
| Equalizer | 13 Band | ||
| Band Frequency | 62.5/ 100/ 160/ 250/ 400/ 630/ 1k/ 1.6k/ 2.5k/ 4k/ 6.3k/ 10k/ 16k Hz | ||
| Level | -09 - +09 (-9dB - +9dB) | ||
| HPF Frequency | Through/ 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250 Hz | ||
| Slope | -6/ -12/ -18/ -24 dB/Oct. | ||
| Gain | -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB | ||
| LPF Frequency | 30/ 40/ 50/ 60/ 70/ 80/ 90/ 100/ 120/ 150/ 180/ 220/ 250 Hz/ Through | ||
| Slope | -6/ -12/ -18/ -24 dB/Oct. | ||
| Gain | -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB | ||
| General | Operating voltage | 12V DC car battery | |
| Installation Dimensions W x H x D | 182 x 112 x 75 mm | ||
| 7-3/16 x 4-7/16 x 2-15/16 inch | |||
| Main Unit Installation size W x H x D(w/o sleeve) | 178 x 100 x 75 mm | ||
| 7-1/16 x 3-15/16 x 2-15/16 inch | |||
| Weight Main unit | 1.2 kg | ||
| 2.7 lbs. | |||
| (Including Sleeve and Trim plate) | |||
