Soundstream Picasso Nano PN5.640D
Great little system amp
Instead of filling your old clunker's trunk with amps and a sub like you did in your youth, you can now power a complete speaker and subwoofer system in your more up-to-date vehicle with one single Soundstream Picasso Nano PN5.640D. This 5-channel amplifier will power your entire system, yet it will fit in some pretty tight locations because of its incredibly compact size. And there's no doubt that the stalking tarantula logo looks pretty cool too.
Power packed
The Picasso Nano PN5.640D puts out 4 channels of 60 watts RMS to your full-range speakers and up to 350 watts to your sub — that's a great balance of power between speaker and sub levels. Or, if your rear speakers don't concern you, you could power high-performance front components with 200 watts RMS each, along with 350 watts for the sub.
Convenient controls and connections
Soundstream gives you all the control features you'll need to craft the sound to match your different components. High-pass filters on the front and rear channels keep low bass out of your full-range speakers so they'll play louder and cleaner. The subwoofer channel features a variable low-pass filter and bass boost, so you can get the best possible performance from your sub. The amp can handle preamp or speaker-level signals so you can use it with a factory receiver that doesn't have preamp outputs.
Product highlights:
5-channel car amplifier
60 watts RMS x 4 at + 200 watts RMS x 1 at 4 ohms
80 watts RMS x 4 at + 350 watts RMS x 1 at 2 ohms
160 watts RMS x 2 bridged at 4 ohms + 350 watts RMS x 1 at 2 ohms
separate variable high-pass filters on front and rear channels (35-350 Hz, 12 dB/octave)
variable low-pass filter on subwoofer channel (30-250 Hz, 12 dB/octave)
variable bass boost on sub channel (0-12 dB at 45 Hz)
Class D amp technology and MOSFET power supply
preamp and speaker-level inputs (RCA and bare wire input harnesses included)
wired remote sub level control included
8-gauge power and ground leads recommended — wiring and hardware not included with amplifier
fuse rating: 40A x 1
12"W x 1-3/4"H x 4-7/8"D
warranty: 1 year
WHATS IN THE BOX:
5-channel amplifier
One 40 amp ATO fuse (installed)
Three 4" RCA input harnesses
Three 7" Speaker level input harnesses
Wired remote control (subwoofer only)
16-1/2' Remote control cable (RJ-25 plug on one end and a proprietary plug on the other)
Four 5/8" Self-tapping screws
Two 1/2" Self-tapping screws
Owner's manual
Specifications on the box
